Tsis muaj txheej txheem phaj

Chemical free CTP version yog hais txog kev siv lub tshuab computer-tsim phaj ua tshuab los luam theej duab thiab duab, tom qab ntawd yaug thiab ua cov dej uas tsis muaj tshuaj.

Xa kev nug

Hauj lwm lawm

Lus Taw Qhia

Chemical free CTP version yog hais txog kev siv lub tshuab computer-tsim phaj ua tshuab los luam theej duab thiab duab, tom qab ntawd yaug thiab ua cov dej uas tsis muaj tshuaj.

Tom qab ntawd cov khoom siv CTP phaj tau luam tawm ntawm lub tshuab. Kuj tseem hu ua dej tsim CTP version.

Ib qho ntawm cov txheej txheem tseem ceeb rau kev ua tiav tsis muaj txheej txheem phaj tshuab yog los ntawm kev siv peb txoj kev: kub kub-tawm, theem hloov, thiab kev ua tshuab. Cov txheej txheem no muab kev xaiv zoo dua thiab ib puag ncig zoo rau kev luam ntawv.

Khoom nta

Thermal ablation technology

Kev kub kub-hauv tshuab yog txheej txheem uas siv lub zog hluav taws xob laser kom tshem tawm cov txheej txheej photosensitive, ua rau lub teeb pom kev rau "hlawv" thiab evaporate, nthuav tawm hydrophilic aluminium puag. Cov thev naus laus zis no tshem tawm qhov xav tau rau kev ua haujlwm tom qab raug thiab tsim cov ntawv luam tawm nrog cov khoom sib txawv hydrophilic thiab roj-tsim zog.

Product Description: Phase-hloov Technology

Theem-hloov tshuab siv hloov pauv theem-hloov cov polymers hauv cov txheej txheej photosensitive, uas muaj cov pab pawg ua haujlwm uas tuaj yeem hloov pauv ntawm oleophilic mus rau hydrophilic nyob rau hauv lub teeb lossis kub. Los ntawm kev raug, cov polymer tuaj yeem hloov nws tus kheej oleophilic lossis hydrophilic zog, yog li nws tuaj yeem ua tiav lub hom phiaj ntawm kev hloov cov roj-dej cov khoom ntawm txheej yam tsis muaj kev cia siab rau hydrophilicity ntawm aluminium phaj puag.

Hauv tshuab ua tshuab

Hauv-tshuab ua tshuab yog ib qho system uas siv cov txheej txheem los tshem tawm cov duab tsis zoo ntawm cov txheej txheem photosensitive ntawm lub tshuab luam ntawv siv cov tshuaj damping, number case, los yog ob qho tib si. Cov cuab yeej no tshem tawm qhov xav tau ntawm kev tsim cov txheej txheem ntxiv, ua tiav lub hom phiaj ntawm kev ua haujlwm tsis muaj zog.

Specifications

Phaj Hom	Tsis zoo-ua hauj lwm, processless, thermal phaj
Daim ntawv thov	Kev lag luam, ntawv xov xwm, ntim tshuab luam ntawv ua haujlwm thiab lwm yam
Puag	Electrochemically grained thiab anodized aluminium substrate
Ntsuas	{{0}}.15mm, 0.20mm,0.24mm, 0.30mm thiab 0.40mm
Txheej xim	Pleev ntsuab
Spectral rhiab heev	800-850 nm
Tshaj tawm lub zog	120 - 150 mJ/cm2 (raws li platesetter nqis thiab daws teeb meem)
Kev daws teeb meem	1% txog 99% @ 200 lpi lossis 25 micron stochastic (raws li platesetter nqis thiab muaj peev xwm ntawm cov duab)
Tus tsim tawm	Tsis muaj tus tsim tawm
Khiav ntev	Txog li 100, 000 impressions (raws li cov duab daws teeb meem, tshuab luam ntawv, tshuaj lom neeg, number case thiab ntawv tej yam kev mob)
Kev nyab xeeb	Lub teeb ntuj (<800 LUX)
Txee lub neej	12 lub hlis (txias-qhuav cia,<35℃,40-80%humidity,away from sunlight)

Cov kev ceev faj

Ua haujlwm nyob rau hauv lub teeb daj kev nyab xeeb.
Siv cov kua nplaum tiv thaiv thaum lub sijhawm luam ntawv nres.
Saib xyuas kom tsis txhob ua rau scuffs thiab creases thaum tuav thiab tso cov phaj.
Txhim kho lub voj voog ua haujlwm zoo ntawm tus tsim tawm.
